Victor Sheets and Plates, located in Abuja, Nigeria, is a trusted manufacturer and supplier of Nickel Alloy 201 Sheets and Plates, known for their exceptional purity, strength, and resistance to harsh environments. Made from high-quality nickel with minimal carbon content, this alloy delivers outstanding corrosion resistance and thermal stability, even in extreme chemical and industrial settings. At Victor Sheets and Plates, we focus on precision manufacturing, ensuring every sheet and plate meets international quality standards. Our Nickel Alloy 201 Sheets and Plates are ideal for industries that require reliability, performance, and durability under challenging operating conditions.
Nickel Alloy 201 Sheets and Plates are composed of approximately 99.6% pure nickel, with trace amounts of iron, copper, manganese, and silicon. The low carbon content minimizes graphitization, ensuring excellent ductility and mechanical strength. The alloy exhibits a tensile strength of around 370 MPa, high flexibility, and impressive corrosion resistance in alkaline and acidic environments. It also maintains stability at elevated temperatures, offering excellent thermal and electrical conductivity. These properties make Nickel Alloy 201 a preferred material for applications that demand purity, toughness, and consistent performance under stress.
| Grade | Nickel Alloy 201 | UNS N02201 |
| Standard | ASTM B162 / ASME SB162 |
| Size | 1000 mm x 2010 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2010 mm x 2010 mm, 2010 mm x 4000 mm |
| Thickness | 0.1mm To 100 mm |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Sheets, Plates, Plain Sheet, Shim Sheet, Strip, Flats |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 201 | 0.02 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 201 | 2.4068 | N02201 | NW 2201 | NA 12 | НП-2 | – | LC-Ni 99 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nickel Alloy 201 Sheets and Plates offer excellent corrosion resistance, particularly in acidic and alkaline environments. They are highly resistant to oxidation and possess superior thermal and electrical conductivity. These alloys are known for their excellent formability, allowing easy shaping and welding. With outstanding mechanical properties at high and low temperatures, Nickel Alloy 201 is ideal for chemical processing, heat exchangers, and electronics applications. It also provides strength and stability, making it suitable for harsh environments and high-stress applications.
|
Nickel 201 plate Stocked Sizes |
|
|---|---|
|
Size (in inches) |
Size (in mm) |
|
.134″ |
3.40 |
|
.125″ |
3.18 |
|
.187″ |
4.75 |
|
.156″ |
3.96 |
|
.312″ |
7.92 |
|
.250″ |
6.35 |
|
.500″ |
12.7 |
|
.375″ |
9.53 |
|
.600″ |
15.9 |
|
.875″ |
22.2 |
|
.750″ |
19.1 |
|
1″ |
25.4 |
|
3″ |
76.2 |
|
1.250″ |
31.8 |
|
1.125″ |
28.6 |
|
1.500″ |
38.1 |
|
2″ |
50.8 |
|
1.750″ |
44.5 |
|
2.500″ |
63.5 |
Nickel Alloy 201 Sheets and Plates are widely used across industries that operate under extreme chemical or thermal conditions. They are commonly employed in the production of caustic soda, chemical processing equipment, and heat exchangers, thanks to their outstanding resistance to alkalis and acids. In the electronics industry, they are used for components requiring high conductivity and stability. Nickel 201 also finds applications in pressure vessels, marine equipment, and food processing systems. Victor Sheets and Plates provides Nickel Alloy 201 Sheets and Plates that deliver long-term reliability, making them ideal for demanding industrial and engineering applications worldwide.
