Victor Sheets and Plates, a well-respected manufacturer and supplier located in Abuja, Nigeria, specializes in top-notch Stainless Steel 347 Sheets and Plates that are engineered for outstanding performance in high-temperature and corrosive settings. These sheets and plates are enhanced with niobium (columbium), which gives them remarkable resistance to intergranular corrosion and helps prevent carbide precipitation during welding. Renowned for their strength, durability, and resistance to oxidation, 347 stainless steel sheets are perfect for applications that require reliability in extreme conditions. Victor is committed to precision manufacturing and upholding international standards, making their 347 Sheets and Plates a reliable choice for the chemical, petrochemical, and aerospace sectors.
Stainless Steel 347 consists of about 17–19% chromium, 9–13% nickel, 0.45–1% niobium (columbium), with carbon content up to 0.08%, and manganese up to 2%. This alloy boasts a tensile strength ranging from 515–690 MPa, a yield strength of around 205 MPa, and an elongation of 40%, ensuring remarkable toughness and ductility. It can withstand oxidation up to 870°C (1600°F) and is resistant to intergranular corrosion in the chromium carbide precipitation range. These characteristics make 347 stainless steel an excellent choice for high-temperature applications where welding and long-term stability are essential.
| 2B Finish Stainless Steel Plate Specification | ASTM A240 / ASME SA240 |
| 2B Finish Stainless Steel Manufacturing Process | Hot Rolled (HR) / Cold Rolled (CR) |
| 2B Finish Stainless Steel Plate Grades | 202 / 304 / 304L / 304H / 309S / 310S / 316 / 316L / 316Ti / 317L / 321 / 321H / 347 / 347H / 904L etc. UNS No. – UNS S30400, UNS S30403, UNS S31008, UNS S31620, UNS S31603, UNS S31603, UNS S31635, UNS S31703, UNS S32100, UNS S34700, UNS S34709, UNS S8904 EN No. – 1.4301, 1.4307, 1.4845, 1.4401, 1.4404, 1.4571, 1.4438, 1.4541, 1.4550, 1.4551, 1.4539 |
| 2B Finish Stainless Steel Plate Thickness | 0.6 MM TO 80 MM THICKNESS |
| 2B Finish Stainless Steel Plate Width | 1250 MM / 1500 MM / 2000 MM / 04 Feet / 05 Feet and Custom Cut Width as Per Requirement |
| 2B Finish Stainless Steel Plate Length | 2400 MM / 2420 MM / 6000 MM / 08 Feet / 10 Feet / Coil Cut and Custom Cut Length as Per Requirement |
| 2B Finish Stainless Steel Plate Surface Finish | 2B, 2D, BA, MATT, MATT PVC, No.4, No.5, SB, HR, No.8, Mirror, Hairline, Brush, Textured, Oil base wet Polished, Both sides Polished available. |
| 2B Finish Stainless Steel Plate Coating | PVC coating Normal / Laser, Film: 100 micrometer, Color: black/white. |
| 2B Finish Stainless Steel Plate Other Testing | NACE MR0175, Ultrasoung TEST, IGC TEST, Intergranular Corrrosion Test as per ASTM A262 Practice E, Charpy Impact Test, Macro, Grain Size, Hardness, etc. |
| 2B Finish Stainless Steel Plate Value Added Services | Gas Cutting / CNC Plasma Cutting / Profiling / Rolling / Bending / Sheet Metal Fabrication / Drill / Punch / Machining / Sand Blasting / SCold Blasting / Heat Treatment |
| 2B Finish Stainless Steel Plate Packaging | Loose / Carrate / Wooden Pallet / Wooden box-a / Plastic Cloth Wraps |
| 2B Finish Stainless Steel Plate Shipment & Transportation | By Road – Truck / Train Partial Load, Full Load, By Sea – Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container / Open Top Container, By Air – Freighter Civil Passenger and Cargo Planes |
| 2B Finish Stainless Steel Plate Material Test Certificate | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS, Bureau of Indian Standards BIS Approved ETC |
| Designation | Chemical composition % by mass max unless stated | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| UNS No | SAE No | AISI No / Common Name | C | Si | Mn | P | S | Cr | Mo | Ni | Others |
| S30100 | 30301 | 301 | 0.15 | 1.00 | 2.00 | 0.045 | 0.030 | 16.0/18.0 | – | 6.0/8.0 | N 0.10 |
| S30103 | – | 301L | 0.03 | 1.00 | 2.00 | 0.045 | 0.030 | 16.0/18.0 | – | 6.0/8.0 | N 0.20 |
| S30153 | – | 301LN | 0.03 | 1.00 | 2.00 | 0.045 | 0.030 | 16.0/18.0 | – | 6.0/8.0 | N 0.07/0.20 |
| S30200 | 30302 | 302 | 0.15 | 0.75 | 2.00 | 0.045 | 0.030 | 17.0/19.0 | – | 8.0/10.0 | N 0.10 |
| S30215 | 30302B | 302B | 0.15 | 2.00/3.00 | 2.00 | 0.045 | 0.030 | 17.0/19.0 | – | 8.0/10.0 | – |
| S30300 | 30303 | 303 | 0.15 | 1.00 | 2.00 | 0.20 | 0.15 min | 17.0/19.0 | – | 8.0/10.0 | |
| S30310 | – | XM-5 (303Plus x) | 0.15 | 1.00 | 2.50/4.50 | 0.20 | 0.25 min | 17.00/19.00 | – | 7.00/9.00 | – |
| S30323 | 30303Se | 303Se | 0.15 | 1.00 | 2.00 | 0.20 | 0.060 | 17.0/19.0 | – | 8.0/10.0 | Se 0.15 min |
| S30330 | – | 303Cu | 0.15 | 1.00 | 2.00 | 0.15 | 0.10 min | 17.0/19.0 | – | 6.0/10.0 | Cu 2.5/4.0; Se 0.10 |
| S30400 | 30304 | 304 | 0.07 | 0.75 | 2.00 | 0.045 | 0.030 | 17.5/19.5 | – | 8.0/10.5 | N 0.10 |
| S30400 A276 for bar | 30304 | 304 | 0.08 | 1.00 | 2.00 | 0.045 | 0.030 | 18.0/20.0 | 8.0/11.0 | ||
| S30403 | 30304L | 304L | 0.030 | 0.75 | 2.00 | 0.045 | 0.030 | 17.5/19.5 | – | 8.0/12.0 | N 0.10 |
| S30403 A276 for bar | 30304L | 304L | 0.030 | 1.00 | 2.00 | 0.045 | 0.030 | 18.0/20.0 | 8.0/12.0 | ||
| S30430 | – | 302HQ | 0.03 | 1.00 | 2.00 | 0.045 | 0.030 | 17.0/19.0 | – | 8.0/10.0 | Cu 3.0/4.0 |
| S30452 | – | XM-21 (304HN) | 0.08 | 1.00 | 2.00 | 0.045 | 0.030 | 18.0/20.0 | – | 8.00/10.00 | N 0.16/0.30 |
| S30453 | – | 304LN | 0.030 | 0.75 | 2.00 | 0.045 | 0.030 | 18.0/20.0 | – | 8.0/12.0 | N 0.10/0.16 |
| S30454 | – | – | 0.03 | 1.00 | 2.00 | 0.045 | 0.030 | 18.0/20.0 | – | 8.0/11.0 | N 0.16/0.30 |
| S30500 | 30305 | 305 | 0.12 | 0.75 | 2.00 | 0.045 | 0.030 | 17.0/19.0 | – | 10.5/13.0 | – |
| S30800 | 30308 | 308 | 0.08 | 1.00 | 2.00 | 0.045 | 0.030 | 19.0/21.0 | – | 10.0/12.0 | – |
| S31600 | 30316 | 316 | 0.08 | 0.75 | 2.00 | 0.045 | 0.030 | 16.0/18.0 | 2.00/3.00 | 10.0/14.0 | N 0.10 |
| S31603 | 30316L | 316L | 0.030 | 0.75 | 2.00 | 0.045 | 0.030 | 16.0/18.0 | 2.00/3.00 | 10.0/14.0 | N 0.10 |
| S31635 | – | 316Ti | 0.08 | 0.75 | 2.00 | 0.045 | 0.030 | 16.0/18.0 | 2.00/3.00 | 10.0/14.0 | Ti 5x (C+N) / 0.70 N 0.10 |
| S31640 | – | 316Cb | 0.08 | 0.75 | 2.00 | 0.045 | 0.030 | 16.0/18.0 | 2.00/3.00 | 10.0/14.0 | Nb 10x C / 1.10 N 0.10 |
| S31653 | – | 316LN | 0.030 | 0.75 | 2.00 | 0.045 | 0.030 | 16.0/18.0 | 2.00/3.00 | 10.0/14.0 | N 0.10/0.16 |
| S31700 | 30317 | 317 | 0.08 | 0.75 | 2.00 | 0.045 | 0.030 | 18.0/20.0 | 3.0/4.0 | 11.0/15.0 | N 0.10 |
| S31703 | – | 317L | 0.030 | 0.75 | 2.00 | 0.045 | 0.030 | 18.0/20.0 | 3.00/4.00 | 11.0/15.0 | N 0.10 |
| S31725 | – | 317LM | 0.030 | 0.75 | 2.00 | 0.045 | 0.030 | 18.0/20.0 | 4.0/5.0 | 13.5/17.5 | N 0.20 |
| S31726 | – | 317LMN | 0.030 | 0.75 | 2.00 | 0.045 | 0.030 | 17.0/20.0 | 4.0/5.0 | 13.5/17.5 | N 0.10/0.20 |
| S31753 | – | 317LN | 0.030 | 0.75 | 2.00 | 0.045 | 0.030 | 18.0/20.0 | 3.0/4.0 | 11.0/15.0 | N 0.10/0.22 |
| S32100 | 30321 | 321 | 0.08 | 0.75 | 2.00 | 0.045 | 0.030 | 17.0/19.0 | – | 9.0/12.0 | Ti 5 x C min/0.70 N 0.10 |
| S34700 | 30347 | 347 | 0.08 | 0.75 | 2.00 | 0.045 | 0.030 | 17.0/19.0 | – | 9.0/13.0 | Nb+Ta 10 x C min/1.0 |
| S34720 | – | 347F | 0.08 | 1.00 | 2.00 | 0.040 | 0.18/0.35 | 17.00/19.00 | 0.75 | 9.00/12.00 | Nb 10xC / 1.10; Cu 0.75; Ta 0.05 |
| S34723 | – | 347FSe | 0.08 | 1.00 | 2.00 | 0.11/0.17 | 0.030 | 17.00/19.00 | 0.75 | 9.00/12.00 | Nb 10xC / 1.10; Cu 0.75; Se 0.15/0.35; Ta 0.05 |
| S34800 | 30348 | 348 | 0.08 | 0.75 | 2.00 | 0.045 | 0.030 | 17.0/19.0 | – | 9.00/13.0 | Nb+Ta 10 x C / 1.00; Ta:0.10 max; Co 0.20 |
| S38400 | 30384 | 384 | 0.04 | 1.00 | 2.00 | 0.045 | 0.030 | 15.0/17.0 | – | 17.0/19.0 | – |
| S.S. | 200 | 202 | 301 | 302 | 303 | 304 | 304L | 309 | 309s | 310 | 310s | 314 | 316 | 316L | 317 | 321 | 347 |
| Tensile Strength | 105 | 105 | 110 | 90 | 90 | 85 | 60 | 90 | 90 | 95 | 95 | 100 | 85 | 78 | 90 | 87 | 92 |
| Yield Strength | 55 | 55 | 40 | 37 | 35 | 35 | 30 | 40 | 40 | 40 | 40 | 50 | 35 | 30 | 40 | 35 | 35 |
| Elongation in 2′ | 55 | 55 | 60 | 55 | 50 | 55 | 55 | 45 | 45 | 45 | 45 | 45 | 55 | 55 | 50 | 55 | 50 |
| Rockwell | 90 | 90 | 85 | 82 | 84 | 80 | 76 | 85 | 85 | 87 | 87 | 87 | 80 | 76 | 85 | 80 | 84 |
| Brinell | 185 | 185 | 165 | 155 | 160 | 150 | 140 | 165 | 165 | 170 | 170 | 170 | 150 | 145 | 160 | 150 | 160 |
| En58M | En58E | En58J&H | En58C | ||||||||||||||
| X12 CrNi17.7 | X2 CrNi18.8 | X5 CrNi18.9 | X5 CrNi18.8 | x5 CrNiMo18.12 | X2 CrNiMo19.1 | X10 CrNiMo18.9 | |||||||||||
| AUST. | AUST. | AUST. | AUST. | AUST. | AUST. | AUST. | AUST. | AUST. | AUST. | AUST. | AUST. | AUST. | AUST. | AUST. | AUST. |
| S.S.Grade | 201 | 202 | 301 | 302 | 304 | 304L | 309 | 309S | 310 | 310S | 316 | 316L | 321 | 347 | 409 | 430 | 434 | 410 |
| Density | 7.9 | 7.9 | 8.0 | 8.0 | 8.0 | 8.0 | 8.0 | 8.0 | 8.0 | 8.0 | 8.0 | 8.0 | 8.0 | 8.0 | 7.7 | 7.8 | 7.8 | 7.8 |
| Sp.Elec. Resist 20C micro | 72 | 72 | 72 | 72 | 72 | 72 | 78 | 78 | 78 | 78 | 74 | 74 | 72 | 73 | 60 | 60 | 60 | 57 |
| Sp. Heat (0-100c) | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 46 | 46 | 46 | 46 |
| Ther. Conductivity | 16.3 | 16.3 | 16.3 | 16.3 | 16.3 | 16.3 | 14.2 | 14.2 | 14.2 | 14.2 | 16.3 | 16.3 | 16.3 | 16.3 | 25.1 | 26.0 | 26.0 | 25.1 |
| 15.7 | 18.4 | 17.0 | 17.2 | 17.3 | 17.3 | 15.0 | 15.0 | 15.9 | 15.9 | 15.9 | 15.9 | 16.6 | 16.6 | 11.7 | 10.4 | 11.9 | 9.9 | |
| Mild water | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X |
| Industrial | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X | ||
| Marine | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X | |||
| Salt Water | X | X | ||||||||||||||||
| Mild | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X |
| Oxidising | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X | X | ||
| Reducing | X | X | ||||||||||||||||
| Abrasion Resistance | Good | Good | Good | Good | Good | Good | Good | Good | Good | Good | Good | Good | Good | Good | Good | Good | Good | Good |
| Cold Forming | Fair | Good | Good | Excel | Excel | Good | Good | Good | Good | Good | Good | Good | Good | Good | Fair | Fair | Fair | Fair |
| Weldability | Good | Good | Excel | Excel | Excel | Excel | Good | Excel | Good | Excel | Excel | Excel | Excel | Excel | Fair | Fair | Fair | Fair |
| Melting Flange | 1400 1420 | 1400 1450 | 1370 1400 | 1400 1430 | 1430 1510 | 1480 1530 | ||||||||||||
| Scaling Temp | 800 | 800 | 800 | 900 | 900 | 900 | 1100 | 1100 | 1100 | 1100 | 900 | 900 | 900 | 900 | 700 | 800 | 800 | 700 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Victor Sheets and Plates based in Abuja, Nigeria, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Stainless Steel 2B Finish Sheets and Plates offer exceptional corrosion resistance, making them ideal for diverse environments, including marine and chemical industries. Their smooth, reflective surface enhances hygiene and ease of cleaning, meeting stringent food processing and medical applications standards. These sheets and plates provide excellent durability, high strength, and resistance to oxidation at elevated temperatures. They are versatile, cost-effective, and suitable for fabrication and welding. The 2B finish also delivers an attractive aesthetic, making them popular in architectural and decorative uses, ensuring both functionality and visual appeal.
Stainless Steel 347 Sheets and Plates are a go-to choice in industries that need to withstand heat and corrosion, like chemical processing, petroleum refining, power generation, and aerospace. They’re perfect for applications such as boiler tubes, exhaust manifolds, furnace parts, heat exchangers, and pressure vessels. Thanks to their stability during welding, these alloys are particularly useful in fabrication and high-pressure settings. Plus, 347 stainless steel finds its place in pharmaceutical equipment, food processing facilities, and marine environments, where resisting oxidation and contamination is crucial. Victor’s 347 Sheets and Plates offer a blend of reliability, strength, and corrosion resistance, ensuring they perform well even in the toughest industrial conditions.
