Victor Sheets and Plates, located in Abuja, Nigeria, has made a name for itself as a leading manufacturer and supplier of Nimonic 90 Sheets and Plates. They specialize in high-performance nickel-chromium-cobalt alloy products that are essential for critical engineering applications. The company is well-regarded for its commitment to quality and precision, serving a variety of industries including aerospace, power generation, petrochemical, and marine engineering. Nimonic 90 is a superalloy that’s precipitation-hardenable, designed to excel in high-temperature and high-stress situations. Victor Sheets and Plates guarantees that each product adheres to international ASTM and AMS standards, providing excellent creep resistance, oxidation resistance, and mechanical strength for extreme thermal environments.
Nimonic 90 is a high-performance nickel-chromium-cobalt alloy enriched with trace elements like titanium and aluminum for superior strength and oxidation resistance. Its typical composition includes Ni (60% min), Cr (18-21%), Co (15-21%), Ti (2-3%), and Al (1-2.5%). Mechanical properties are equally impressive, featuring a tensile strength of 965 MPa, yield strength of 690 MPa, and exceptional creep resistance up to 920°C. Known for its outstanding durability and thermal stability, Nimonic 90 is ideal for demanding environments such as turbine blades, combustion chambers, and high-stress applications.
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Shims Thickness : | Range from .01″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Plate, Sheet and Strip : | BS HR 203, DIN 17750, AECMA PrEN2293, AECMA PrEN2302, AECMA PrEN2411, ISO 6208 |
| Grade | Ni | Cr | Co | Ti | Al | C | Si | Cu | Fe | Mn | B | S | Zr | Pb |
| Nimonic 90 | Bal | 18-21 | 15-21 | 2-3 | 1-2 | 0.2 max | 1.0 max | 0.2 max | 1.5 max | 1.0 max | 0.02 max | 0.015 max | 0.15 max | 0.0020 max |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 1150 MPa | 725 MPa | 30% |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
The composition of Nimonic 90 Sheets and Plates primarily includes nickel (the balance), chromium (18–21%), cobalt (15–21%), titanium (2.0–3.0%), aluminum (1.0–2.5%), along with trace amounts of iron, copper, silicon, and carbon. This alloy is known for its remarkable mechanical stability and oxidation resistance, even at temperatures reaching up to 950°C. Typical mechanical properties feature a tensile strength ranging from 900 to 1100 MPa, a yield strength of 600 MPa, and an elongation of 20%. Nimonic 90 stands out for its exceptional fatigue, creep, and stress-rupture strength, making it a top choice for high-temperature, high-stress applications.
Nimonic 90 Sheets and Plates offer exceptional advantages for high-performance applications. They exhibit superior heat resistance, making them suitable for extreme temperatures up to 920°C. The alloy’s high tensile and yield strength ensures durability under mechanical stress. Excellent oxidation and corrosion resistance enhance longevity in challenging environments. With superior creep and fatigue resistance, they are ideal for high-stress and cyclic-load conditions. Lightweight yet robust, these sheets and plates are widely used in aerospace, power generation, and automotive industries, delivering reliability and efficiency in demanding engineering and industrial applications.
| WEIGHT PER NIMONIC SHEET : | ||||
| THICKNESS IN MM | SIZE IN MM | WEIGHT KG/M2 | ||
| 2000 X 1000 | 2500 X 1250 | 3000 X 1500 | ||
| 0.18 | 2.88 | – | – | 1.44 |
| 0.20 | 3.20 | – | – | 1.60 |
| 0.22 | 3.52 | – | – | 1.76 |
| 0.24 | 3.84 | – | – | 1.92 |
| 0.27 | 4.32 | – | – | 2.16 |
| 0.28 | 4.48 | – | – | 2.24 |
| 0.32 | 5.12 | – | – | 2.56 |
| 0.38 | 6.08 | – | – | 3.04 |
| 0.44 | 7.04 | 11.00 | – | 3.52 |
| 0.50 | 8.00 | 12.50 | – | 4.00 |
| 0.56 | 8.96 | 14.00 | – | 4.48 |
| 0.63 | 10.08 | 15.75 | – | 5.04 |
| 0.75 | 12.00 | 18.75 | – | 6.00 |
| 0.88 | 14.08 | 22.00 | – | 7.04 |
| 1.00 | 16.00 | 25.00 | 36.00 | 8.00 |
| .1.13 | 18.08 | 28.25 | 40.00 | 9.04 |
| 1.25 | 20.00 | 31.25 | 45.00 | 10.00 |
| 1.38 | 22.03 | 34.50 | 50.00 | 72.00 |
| 1.50 | 24.00 | 37.50 | 54.00 | 12.00 |
| 1.75 | 28.00 | 43.75 | 63.00 | 14.00 |
| 2.00 | 32.00 | 50.00 | 72.00 | 16.00 |
| 2.25 | 36.00 | 56.25 | 81.00 | 18.00 |
| 2.50 | 40.00 | 62.50 | 90.00 | 20.00 |
| 2.75 | 44.00 | 68.75 | 99.00 | 22.00 |
| 3.00 | 48.00 | 75.00 | 108.00 | 24.00 |
| 3.25 | 52.00 | 81.25 | 117.00 | 26.00 |
| 3.50 | 56.00 | 87.50 | 126.00 | 28.00 |
| 3.75 | 60.00 | 93.75 | 135.00 | 30.00 |
| 4.00 | 64.00 | 100.00 | 144.00 | 32.00 |
| 4.25 | 68.00 | 106.25 | 153.00 | 34.00 |
| 4.50 | 72.00 | 112.50 | 162.00 | 36.00 |
| 5.00 | 80.00 | 125.00 | 180.00 | 40.00 |
| 5.50 | 88.00 | 137.50 | 198.00 | 44.00 |
| 6.00 | 96.00 | 150.00 | 216.00 | 48.00 |
| 6.50 | 104.00 | 162.50 | 234.00 | 52.00 |
| 7.00 | 112.00 | 175.00 | 252.00 | 56.00 |
| 7.50 | 120.00 | 187.50 | 270.00 | 60.00 |
| 8.00 | 128.00 | 200.00 | 288.00 | 64.00 |
Yes, we offer custom sizes for Nimonic 90 Sheets and Plates to meet specific project needs. Our team at Victor Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
Nimonic 90 Sheets and Plates are widely used in the aerospace and gas turbine sectors for crafting turbine blades, discs, combustion chambers, and exhaust systems, thanks to their outstanding heat and oxidation resistance. You’ll also find them in power generation plants, nuclear reactors, and automotive turbocharger components, where materials need to maintain their strength even at high temperatures. Plus, Nimonic 90 is a go-to for fasteners, springs, and high-performance engineering assemblies that face cyclic thermal stresses. Its unique blend of creep resistance, durability, and thermal stability makes it the top choice for demanding high-temperature and corrosive industrial environments that require reliability and long-lasting performance.
