Victor Sheets and Plates, a top-notch manufacturer and supplier based in Abuja, Nigeria, offers high-quality SA537 Class 1 Boiler Sheets and Plates that adhere to international standards for pressure vessel applications. These plates are crafted from carbon-manganese-silicon steel, specifically designed for moderate to high-pressure service, and are heat-treated (quenched and tempered) to enhance their strength and toughness. With outstanding weldability, impact resistance, and durability, SA537 Class 1 is perfect for boilers, pressure vessels, and heat exchangers in demanding industrial settings. Victor Sheets and Plates is committed to delivering consistent product quality, making these plates a trusted choice for the power, petrochemical, and energy industries.
SA537 Class 1 is composed of carbon (≤0.24%), manganese (0.60–1.60%), silicon (0.15–0.50%), phosphorus (≤0.025%), and sulfur (≤0.025%). The plates undergo a quenching and tempering process, resulting in an impressive blend of strength and ductility. They boast a tensile strength ranging from 485 to 620 MPa, a yield strength of about 345 MPa, and an elongation of at least 20%. These characteristics ensure exceptional impact toughness, weldability, and formability, even at moderate to high temperatures. The alloy’s well-balanced chemistry enables it to excel in pressure vessel and boiler applications where structural integrity and thermal stability are crucial.
Grade : ASME SA 537 CL.1 Boiler and Pressure Vessel Steel Plates
Width : 1000mm-4500mm
Thickness : 5mm-150mm
Length : 3000mm-18000mm
Supply Condition : As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
Impact tested : -52° C
Tempering : Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F.
Applications : Used for Boilers and Pressure Vessels Application.
Process of Manufacturing : Hot-Rolled (HR)
| C | Mn | P | S | Si | Cr | Cu | Ni | Mo | |
| ≤ 40 mm | > 40 mm | ||||||||
| 0.24 max | 0.70/1.35 | 1.00/1.60 | 0.035 | 0.035 | 0.15/0.50 | 0.025 | 0.35 | 0.25 | 0.080 |
| Grade | Heat Treatment | Yield (MPa) | Tensile (MPa) | Elongation | Thickness | |
| A50mm | A200mm | |||||
| SA537 Class 1 | Normalized | 345 | 485/620 | 22% | 18% | ≤ 65 |
| 310 | 450/585 | 22% | 18% | > 65 ≤ 100 | ||
| Steel Grade | JIS | Germany |
| ASTM/ASME | G3115 | DIN17155 |
| A537 / SA537 | SPV36 | 19Mn5 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
SA537 Class 1 Boiler Sheet and Plate offer excellent strength, toughness, and resistance to pressure, making them ideal for use in high-temperature and high-pressure applications like boilers and pressure vessels. Their superior weldability allows for easy fabrication, while their resistance to cracking and corrosion enhances reliability in demanding environments. This steel is heat-treated to ensure improved mechanical properties, long-term durability, and performance. With excellent formability and impact resistance, SA537 Class 1 is a trusted choice for power generation, petrochemicals, and manufacturing industries.
SA537 Class 1 Boiler Sheets and Plates are widely utilized in pressure vessels, boilers, heat exchangers, and storage tanks that operate under moderate to high pressure. They’re perfect for industries like petrochemical, oil refining, thermal power, and gas processing, where durability and resistance to stress and heat are essential. These plates also find their place in steam generators, reactors, and industrial autoclaves, providing reliable performance even under cyclic loading and varying pressures. Thanks to their impressive mechanical strength, impact resistance, and weldability, SA537 Class 1 plates guarantee safe and efficient operation in industrial pressure equipment and energy generation systems.
