Victor Sheets and Plates, a reputable manufacturer and supplier located in Abuja, Nigeria, proudly offers top-notch Super Duplex Steel S32750 Circles. These circles are celebrated for their remarkable strength, resistance to corrosion, and long-lasting durability. Crafted specifically for challenging and corrosive environments, they are produced in line with international standards to guarantee reliability and precision. The S32750 grade is known for its outstanding resistance to pitting, crevice corrosion, and chloride stress corrosion cracking. Victor’s Super Duplex Steel Circles find extensive application in industries such as chemical, marine, oil & gas, and power generation, where exceptional mechanical properties and longevity are crucial.
Super Duplex Steel S32750 Circles consist of about 25% chromium, 7% nickel, and 4% molybdenum, along with nitrogen and tungsten to boost strength and corrosion resistance. This unique dual-phase microstructure (austenitic-ferritic) strikes a perfect balance between toughness and hardness. The material showcases a tensile strength ranging from 800 to 1000 MPa, a yield strength of around 550 MPa, and an elongation of up to 25%. It excels in chloride-rich and acidic environments, maintaining impressive structural integrity under pressure. Additionally, the alloy offers excellent weldability, fatigue resistance, and oxidation strength at high temperatures, making it perfect for heavy-duty applications.
| Specifications | ASTM A240 / ASME SA240 |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Thickness | 1 mm To 100 mm |
| Diameter | Upto 2000 mm |
| Circle | 3″ DIA up to 38″ DIA 1500 lbs max |
| Rings | 3″ OD up to 48″ OD Up to 900 lbs max |
| Cutting | Plazma & Machined Cut |
| Finish | HR, CR, 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Cold Rolled Circle, Small Flat Circle, Industrial Circle, Perforated Circle, Forged Steel Circles, Cnc Finish Circle, Polished Unique Circle, Hot Rolled Circle, Fey Laminar Rings, Proof Machined Rings, Cold Rolled Rings, Hot Rolled Rings, McInnes Rolled Rings, Die-Formed Rings, Forging Rings, CNC Machined Rings. |
| STANDARD | WERKSTOFF NR. | UNS |
| Super Duplex S32750 | 1.4410 | S32750 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32750 | 0.030 max | 1.20 max | 0.80 max | 0.035 max | 0.020 max | 24.00 – 26.00 | 3.00 – 5.00 | 6.00 – 8.00 | 0.24 – 0.32 | 58.095 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32750 | 7.8 | 0.281 | 1350 | 2460 |
Victor Sheets and Plates based in Abuja, Nigeria, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Super Duplex S32750 Circle offers several advantages, making it ideal for demanding applications. Its exceptional corrosion resistance, particularly against pitting, crevice, and stress corrosion cracking, ensures longevity in harsh environments, including marine and chemical industries. The alloy’s high tensile and yield strength provide excellent durability and reliability, even under high pressure. Its balanced microstructure of austenite and ferrite enhances mechanical properties, making it highly resistant to fatigue and wear. Additionally, Super Duplex S32750 offers good weldability and is suitable for high-temperature applications, ensuring superior performance and extended service life.
Yes, we offer custom sizes for Super Duplex Steel S32750 Circle to meet specific project needs. Our team at Victor Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| Size | 18 G. | 19 G. | 20 G. | 22 G. | 24 G. | 26 G. |
| .4.5 | .0-107 | 0-085 | 0-080 | 0-062 | 0.049 | 0-040 |
| 5 | 0-120 | 0-095 | 0-090 | 0-070 | 0-055 | 0-045 |
| 5.5 | 0-146 | 0-119 | 0-109 | 0-085 | 0-066 | 0-054 |
| 6 | 0-172 | 0-136 | 0-130 | 0-100 | 0-079 | 0-064 |
| 6.5 | 0-200 | 0-153 | 0-150 | 0-128 | 0-093 | 0-074 |
| 7 | 0-235 | 0-190 | 0-176 | 0-136 | 0-107 | 0-088 |
| 7.5 | 0.270 | 0.212 | 0.201 | 0-157 | 0-123 | 0-100 |
| 8 | 0-307 | 0-240 | 0-230 | 0-180 | 0-140 | 0-115 |
| 8.5 | 0-347 | 0-270 | 0-262 | 0-202 | 0-156 | 0-130 |
| 9 | 0-388 | 0-330 | 0-301 | 0-230 | 0-178 | 0-145 |
| 9.5 | 0-472 | 0-342 | 0-324 | 0-252 | 0-198 | 0-162 |
| 10 | 0-480 | 0-380 | 0-360 | 0-280 | 0-220 | 0-180 |
| 11 | 0-580 | 0-450 | 0-435 | 0-338 | 0-266 | 0-218 |
| 12 | 0-690 | 0-540 | 0-518 | 0-403 | 0-318 | 0-253 |
| 13 | 0-811 | 0-640 | 0-508 | 0-608 | 0-371 | 0-304 |
| 14 | 0-940 | 0-750 | 0-708 | 0-558 | 0-430 | 0-352 |
| 15 | 1-080 | 0-860 | 0-808 | 0-650 | 0-495 | 0-405 |
| 16 | 1-228 | 0-960 | 0-921 | 0-736 | 0-563 | 0-460 |
| 17 | 1-382 | 1-080 | 0-940 | 0-809 | 0-635 | 0-560 |
| 18 | 1-595 | 1-200 | 1-116 | 0-907 | 0-712 | 0-683 |
| 19 | 1-732 | 1-350 | 1-300 | 1-010 | 0-794 | 0-750 |
| 20 | 1-920 | 1-400 | 1-340 | 1-120 | 0-880 | 0-785 |
| RAW MATERIAL | MAX. HARDNESS | TEMPERATURE | ABBREVIATIONSMARKER | |
| BRUCELLOSIS | ROCKWELL | |||
| SOFT IRON | 90 | 56 | -60 540 | D |
| LOW CB STEEL | 120 | 68 | -40 540 | S |
| 304SS | 160 | 83 | -250 700b | 304 |
| 304LSS | 150 | 83 | -250 450 | 304L |
| 316SS | 160 | 83 | -200 700b | 316 |
| 316LSS | 150 | 83 | -200 450 | 316L |
| 321SS | 160 | 83 | -200 700b | 321 |
| 347SS | 160 | 83 | -200 700b | 347 |
| 410SS | 170 | 86 | -40 650 | 410 |
| 5Cr-0.5Mo | 130 | -29 650 | ||
| COPPER | 80 | -100 315 | ||
| ALUMINUM | 35 | -200 425 | ||
| INCONEL 600 | 150 | -100 1095 | ||
| INCOLOY 825 | 160 | -100 1095 | ||
| MONEL 400 | 150 | -100 760 | ||
| TITANIUM | 215 | -200 540 | ||
| NICHEL 200 | 110 | -200 760 | ||
| HASTELLOY C276 | 200 | -100 1095 | ||
Super Duplex Steel S32750 Circles are widely utilized in various sectors, including chemical processing plants, offshore oil rigs, desalination units, marine equipment, and power generation systems. Their remarkable resistance to corrosion, erosion, and harsh seawater conditions makes them ideal for applications like heat exchangers, pressure vessels, pump components, flanges, and valve parts. Additionally, these circles find their place in industries such as pulp & paper, petrochemical, and construction, where both high strength and corrosion resistance are essential. Victor’s S32750 Circles offer outstanding machinability, durability, and dimensional stability, ensuring they perform reliably in demanding industrial settings, whether onshore or offshore.
