Victor Sheets and Plates is a well-respected manufacturer and supplier located in Abuja, Nigeria, that specializes in top-notch Zirconium Sheets and Plates. The company has built a solid reputation for providing precision-engineered products that adhere to global quality standards. The Zirconium sheets and plates from Victor Sheets and Plates are highly regarded for their remarkable corrosion resistance, impressive strength, and outstanding durability, even in extreme conditions. Catering to industries like chemical processing, nuclear energy, aerospace, and marine engineering, the company guarantees reliable, long-lasting, and high-performance zirconium products designed to meet a wide range of industrial needs.
Zirconium Sheets and Plates are mainly made up of zirconium (Zr), with small quantities of hafnium (up to 4.5%) and trace elements such as iron, oxygen, and nitrogen. They are known for their excellent resistance to corrosion, particularly against strong acids and alkalis. These zirconium sheets boast a tensile strength of about 330–580 MPa, good ductility, and a high melting point of around 1855°C. Their low neutron absorption cross-section and exceptional thermal stability make them perfect for high-performance and nuclear-grade applications, where strength, resistance, and purity are essential.
| Standard Specification : | ASTM B551 / ASME SB551 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Zirconium and Zirconium Alloys Chemical Composition | |||||||||
| Products | Chemical Composition (wt%≤) | ||||||||
| Sn | Fe | Ni | Cr | Fe+Cr | Fe+Ni+Cr | Nb | Al | B | |
| R60001 Nuclear Grade Pure Zirconium (Zr-0) | 0.005 | 0.15 | 0.0070 | 0.02 | – | – | – | 0.0075 | 0.0005 |
| R60802 (Zr-2) | 1.20-1.70 | 0.07-0.20 | 0.03-0.08 | 0.05-0.15 | – | 0.18-0.38 | – | 0.0075 | 0.0005 |
| R60804 (Zr-4) | 1.20-1.70 | 0.18-0.24 | 0.0070 | 0.07-0.13 | 0.28-0.37 | – | – | 0.0075 | 0.0005 |
| R60901 (Zr-2.5Nb) | 0.0050 | 0.150 | 0.0070 | 0.02 | – | – | 2.4-2.8 | 0.0075 | 0.0005 |
| R60904 (Zr-2.5Nb) | 0.010 | 0.065 | 0.0035 | 0.01 | – | – | 2.5-2.8 | 0.0075 | 0.0005 |
| Zirconium and Zirconium Alloys Sheet & Plate Mechanical Properties | |||||
| Grades | |||||
| Products | R60700 | R60702 | R60704 | R60705 | R60706 |
| Tensile strength, min, ksi (MPa) | – | 55 (380) | 60 (415) | 80 (550) | 74 (510) |
| Yield strength, min, ksi (MPa) | – | 30 (205) | 35 (240) | 55 (380) | 50 (345) |
| Tensile strength, max, ksi (MPa) | 55 (380) | – | – | – | – |
| Yield strength, max, ksi (MPa) Sheet, Plate and Strip | 44 (305) | – | – | – | – |
| Elongation in 2 in. or 50 mm, min, % | 20 | 16 | 14 | 16 | 14 |
| Bend test radius | 5T | 5T | 5T | 3T | 2.5T |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Victor Sheets and Plates based in Abuja, Nigeria, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Zirconium sheets and plates offer several advantages, including exceptional corrosion resistance, especially in harsh environments like acids, seawater, and high-temperature conditions. They possess excellent strength, toughness, and high melting points, making them ideal for demanding applications in aerospace, nuclear, and chemical industries. Zirconium is also biocompatible, making it suitable for medical and dental uses. Additionally, its low thermal expansion and superior fatigue resistance enhance its performance in critical applications. The material’s durability, combined with excellent weldability and formability, ensures long-lasting, reliable performance in various industrial sectors.
Yes, we offer custom sizes for Zirconium Sheets and Plates to meet specific project needs. Our team at Victor Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
Zirconium Sheets and Plates find extensive use in industries that require superior corrosion resistance and high-temperature performance. In the chemical sector, they are utilized for creating heat exchangers, reactors, and evaporators. The nuclear industry employs them for fuel cladding and reactor core components due to their low neutron absorption. In aerospace and marine applications, zirconium plates are used in components that face harsh environments. Additionally, they are found in surgical instruments, electronic devices, and high-performance alloys, providing unmatched strength, durability, and chemical stability in demanding operational conditions.
